82 ADV100 • Quick installation guide - Specifications and connection
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
4 LimCop pos/neg
20.4 2358 Torque lim sym/p src LINK 16/32BIT 6000 0 16384 ERWZ F�S
L�LIM
20.5 2370 Torque lim neg src LINK 16/32BIT 6000 0 16384 ERWZ F�S
L�LIM
20.6 2360 Torque lim Pos Inuse A FLOAT 16/32BIT 0.0 0.0 0.0 ER FVS
20.7 2362 Torque lim Neg Inuse A FLOAT 16/32BIT 0.0 0.0 0.0 ER FVS
20.8 2380 Dig torque ref 1 perc FLOAT 16/32BIT 0.0 -300.0 300.0 ERW F�S
20.9 2382 Torque ref 1 src LINK 16/32BIT 3104 0 16384 ERWZ F�S
L�VREF
20.10 2384 Torque ref filter ms FLOAT 1.0 0.1 10.0 ERW F�S
20.11 2386 Torque ref perc FLOAT 16/32BIT 0.0 0.0 0.0 ER F�S
20.12 2366 Torque curr lim Red A FLOAT 16/32BIT CALCF 0.0 CALCF ERWS FVS
20.13 2368 Torque clim Red src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
21 - VF PARAMETERS
21.1 2400 Voltage flux boost perc FLOAT CALCF 0.0 15.0 RWS �V�
21.2 2402 Voltage boost gain V/A FLOAT CALCF 0.0 0.0 ERWS �V�
21.3 2404 Voltage torque boost ENUM Enable 0 1 ERWZ �V�
0 Disable
1 Enable
21.4 2406 Vf voltage V FLOAT CALCF 10.0 690.0 ERWZS �V�
21.5 2408 Vf frequency Hz FLOAT CALCF 10.0 2000.0 ERWZS �V�
21.6 2410 Vf voltage 1 V FLOAT CALCF CALCF CALCF ERWZS �V�
21.7 2412 Vf frequency 1 Hz FLOAT CALCF 0.0 CALCF ERWZS �V�
21.8 2414 Vf voltage 0 V FLOAT 0.0 0.0 CALCF ERWZS �V�
21.9 2430 Vf shape ENUM Linear 0 2 ERWZS �V�
0 Linear
1 Custom
2 Quadratic
21.10 2440 Slip comp Hz FLOAT CALCF 0.0 10.0 RWS �V�
21.11 2442 Slip comp filter ms UINT16 200 50 5000 ERW �V�
21.12 2444 Slip comp mode ENUM Open loop 0 1 ERWZ �V�
0 Open loop
1 Closed loop
21.13 2446 Slip P gain perc FLOAT 1.0 0.0 100.0 ERWS �V�
21.14 2448 Slip I gain perc FLOAT 1.5 0.0 100.0 ERWS �V�
21.15 2460 Vfcurrent lim P gain Hz/A FLOAT CALCF 0.0 1000.0 ERWS �V�
21.16 2462 Vfcurrent lim I time ms FLOAT CALCF 1.0 50.0 ERWS �V�
21.17 2470 Damping gain perc UINT16 0 0 100 ERW �V�
21.18 2472 Damping threshold 1 Hz INT16 20 5 100 ERW �V�
21.19 2474 Damping threshold 2 Hz INT16 30 5 100 ERW �V�
21.20 2480 Vf min frequency Hz FLOAT 1.0 0.2 5.0 ERW �V�
21.21 2482 Vf min freq delay ms UINT16 800 0 5000 ERW �V�
21.22 2490 Dig Vf scale FLOAT 16/32BIT 1.0 0.0 1.0 ERWZ �V�
21.23 2492 Vf scale src LINK 16/32BIT 3374 0 16384 ERW �V�
L�VREF
22 - FUNCTIONS
22.1 - FUNCTIONS/INERTIA COMP
22.1.1 3100 Inertia comp kgm2 FLOAT 0.0 0.0 100.0 ERWS F�S
22.1.2 3102 Inertia comp filter ms UINT16 30 1 100 ERW F�S
22.1.3 3104 Inertia comp mon perc FLOAT 16/32BIT 0.0 0.0 0.0 ER F�S
22.2 - FUNCTIONS/DC BRAKING
22.2.1 3150 DC braking cmd src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
22.2.2 3152 DC brake mode ENUM Off 0 3 ERW FVS
0 Off
1 At Stop
2 On Command
3 OnCmd & AtStop
22.2.3 3154 DC brake delay s FLOAT 0.5 0.00 30.0 ERW FVS
22.2.4 3156 DC brake duration s FLOAT 1.0 0.01 30.0 ERW FVS
22.2.5 3158 DC brake current perc FLOAT 50.0 0.0 150.0 ERW FVS
22.2.6 3160 DC brake state ENUM 16BIT Not active 0 1 ER FVS
0 Not active
1 Active
22.3 - FUNCTIONS/MOTOR OVERLOAD
22.3.1 3200 Motor ovld enable BIT 0 0 1 ERW FVS
22.3.2 3202 Motor ovld factor perc FLOAT 150.0 100.0 300.0 ERWS FVS
22.3.3 3204 Motor ovld time s FLOAT 30.0 10.0 300.0 ERWS FVS
22.3.4 3206 Motor service factor perc FLOAT 100.0 25.0 200.0 ERWS FVS
