Gema MagicControl 4.0 - Symbols

Rev. 01 12/21
MagicControl 4.0 (CM40) Product description
•
19
Symbols
fig.
6
Navigation bar
Plant overview
Information bar
-
Operating mode dependent bar
Login status bar
Function keys
The function keys are distributed on the user interface.
Automatic operation
mode
Cleaning operation
mode
Manual operation mode
Main menu
Plant - OFF
(Press and hold 2
seconds)
Cyclone
Powder management
Filter ON/OFF or
High/Low frequency
Guns ON/OFF ﴾=
powder﴿
Squeegee ON/OFF
Floor blow-off ON/OFF
Guns‐External cleaning
ON/OFF
Axes move to reference
position
Axes ON/OFF
Safety grid (access
release ON/OFF)
Reference axes
Start/Cancel
