Gema MagicControl 4.0 User Manual

Rev. 01 12/21
MagicControl 4.0 (CM40) Batch Management (Basic Version)
•
73
Batch Management (Basic Version)
MagicControl CM40
Introduction
Batch management is a standard component of the CM40 control unit and
is used to record the consumed powder, divided into production batches.
The recorded consumption data is continuously updated and then
displayed on the screen in tabular form. If a height light grid is present, in
addition to the powder consumption, the coated side elevation area is
also recorded. In the basic version, batch management is operated
manually.
Operation
The basic version of Batch Management allows you to log the most
important information for each individual production batch in the simplest
possible way. All information about the respective batch, the continuously
added powder quantities as well as batch start and stop are entered
manually in an input mask (Fig. 78). Batch management calculates the
total time and powder consumption from the data entered and adds them
to a report (Fig. 79).
Fig.
78
: Input mask
