Gema MagicControl 4.0 User Manual

Rev. 01 12/21
72
•
Machine data MagicControl 4.0 (CM40)
Cleaning mode
average
Total cleaning time divided by number of
color changes
Number of color
changes
Number of started color changes
Piece counter
Number of objects detected by the object
recognition (objects hanging on top of each
other are counted as a single object)
Coating area
Means the lateral object surface determined
by the object recognition.
– Only in conjunction with light grid
Distance
Traveled conveyor distance after release of
the coating system
Time On
Conveyor running time (FL)
Stop
Conveyor standstill (FS)
In stop state
100 x FS / (FL + FS)
Number of stops
Number of activated conveyor stops (by
operator, conveyor system, system error)
After filter
After filter running time
Gun
Coating time (trigger time)
Axis
Axis running time
Fig.
77
: Gun and axis operating hours screen
