Gema MagicControl 4.0 User Manual

Rev. 01 12/21
22
•
Product description MagicControl 4.0 (CM40)
– Before every color change
– Before switching off the plant
The higher the requirement for cleanliness, the higher the time
expenditure will be.
The cleaning of the components is partially automated, however, some of
them must be cleaned manually.
During cleaning, no objects may be present in the booth and no
objects may enter the booth.
User levels and access
The plant control offers the possibility to define the access rights of the
different users. Access is only possible after entering the appropriate
password. Certain functions are available depending on the user level,
which is defined in advance.
The software has 5 user levels as standard predefined by Gema:
– User level 0 (admin)
– User level 1 (Gema service)
– User level 2 (user 1)
– User level 3 (user 2)
– User level 4 (user 3)
These user levels are pre-programmed and cannot be changed.
The functions available depending on the user level are explained below.
Functions available at user level
User
Admin
Gema
Service
user 1
user 2
user 3
User level
0
1
2
3
4
User groups
Administ
rator
Service
Supervis
or
Operator
Painter
The panel can be used without any
limitation

–
–
–
–
Level for specialized Gema staff


–
–
–
Configuration possible

–
–
–
–
Plant parameters can be modified



–
–
Correction values can be modified



–
–
Sequence control programs can be
modified



–
–
Application parameters can be modified
(axes, guns, pretravel/overtravel, daily
correction)




–
The user can rename or copy the
existing application data




–
The user can activate the existing
application data





