Rev. 01 12/21
MagicControl 4.0 (CM40) Product description
21
Operating modes
The plant can be operated in the 3 operating modes automatic (AUTO),
manual (MAN) and cleaning (CLN). The operating modes are selected
using the navigation bar on the operating panel.
Automatic operating mode (AUTO)
Predefined programs are processed in the operating mode AUTO. All
axes and work processes are controlled by the program. The operating
mode supports gap control.
Automatic operation is only possible if object recognition and a
pulse generator are present.
– The guns and axes start automatically, based on the feedback from
the object recognition
– Dynamic positioning of guns and axes by object recognition
– Coating process is interrupted when the conveyor stops
– Guns can be selected or deselected
– Object changes are carried out manually or automatically
– Daily correction of the powder output can be modified
– Status display of object recognition
Manual operating mode (MAN)
MAN is the manual operating mode for operating simple plants without
gap control or object recognition and for testing and running-in the
application.
– Guns and axes are individually controlled manually by the user
– Manual positioning of guns and axes by user
– Coating process is interrupted when the conveyor stops
– Guns can be selected or deselected
– Object change is carried out manually
– Daily correction of the powder output can be modified
– Status display of object recognition
Cleaning operating mode (CLN)
This operating mode allows the user to clean the booth and other plant
components.
– Cleaning procedures for guns, axes and booth
– Cleaning procedures for powder management system are released
Utilization of this operating mode:
– After switching on the plant, if very high quality is required on initial
coating application
