Information about the functional mode of the individual system
components can be found in the respective enclosed documents.
1. Enter the relevant data in the four input fields to describe the
production batch to be tracked: Name, Object, Notes and Color
code.
2. Press the Start key to start recording.
– The Duration in field 3 starts counting and is continuously
updated.
3. In field 4 (weight field), enter the quantity of fresh powder supplied
(e.g. 25 kg).
4. Press the + key to add the powder volume (weight field) to the
current batch recording.
– This step can be done once or with each additional supply of
fresh powder (e.g. powder box). The Powder consumption is
updated accordingly in field 3.
5. When the batch is finished, weigh or estimate the remaining or
recovered powder. Enter the value in field 4 (weight field) and
subtract it from the current batch recording using the - key.
– The Powder consumption is updated accordingly in field 3.
6. Press the Stop key to stop the recording.
– The corresponding data is updated and displayed in field 3.
7. Press the Scroll key to go to the overview page.
– The recorded batch information is automatically transferred and
chronologically listed when the Stop key is pressed. A maximum
of a thousand lines per month can be displayed here. Use the
Scroll key to switch to the input mask.
: Chronological listing of batches produced
Optionally, the saved Batch Management files can be copied to a
computer or file server via an ftp://-path – for more information refer to the
document “Advanced Batch Management”.
