1 rear storage rack assembly 2 seat assembly 3 left front guard plate 4 right front guardplate 5 left
guard plate 6 right guard plate 7 rear left steering lamp assembly 8 left decoration plate of guard plate
9 rear right steering lamp assembly 10 right decoration plate of guard plate 11 fuel tank assembly
A
Note: in removing fuel
tank, turn fuel switch to
"OFF".
B
do not damage body cove
r
in removal an
d
installation. Do no
t
damage hook on cover.
Match panel and cove
r
p
late of body cover wit
h
the slot respectively.
Location of hook of eac
h
p
art shall be right i
n
installation.
