1 front rim 16×1.6 2 vacuum tyre 80/80-16 3 front outer bushing 4 front axle oil seal 5 bearing 6201-2RS
6 screw M6×20 7 front brake disc 8 valve cap 9 valve 10 front wheel middle bushing 11 pinion stand
assembly 12 front wheel axle M12×1.5×153.7
Front suspension
A
Bolt 3 mounting torque
force:22-29
N·m
B
Bolt 6 mounting torque
force: 37-44
N·m
Ball upper quantity: 21
pcs
C
Ball lower quantity: 21
pcs
