Generic Onyx 50 User Manual

- 114 -
9.Fuel tank/seat
Preparation documents-----------9.1
Failure diagnosis-----------9.2
Fuel tank/seat--------9.3
9.1 Preparation documents
Note:
The removing site shall be ventilated and away from fire.
Before removing fuel tank, shut motor and turn fuel switch to "OFF".
In installation tighten the bolt nut to defined torque force.
After installation, check and see whether all parts and operation are right.
Preparation standard
Item Standard
Available usage
limit
Gasoline tank capacity 5.5 L±0.2L /
Locking torque force
Fuel tank standing bolt 5 - 9 N·m
Helmet barrel standing bolt 5 - 9 N·m
9.2 Failure diagnosis
Decreasing gasoline
Natural consumption of gasoline
Leakage of gasoline
