- 45 -
Battery removal
Remove the rubber pad (1) of pedal.
Remove the clamp bolt and clamp of battery.
irst remove the negative wire and then
remove the positive wire.
Take the battery (5) from the battery container.
Warning！
The tools for removing the positive electrode should not contact the flame, otherwise it will be very dangerous
that the damaged battery will cause fire.
Install the battery following the opposite sequence.
Do not disconnect the battery during the adjustment of motorcycle, otherwise inner component of the motorcycle
may be damaged.
Warning!
First positive and then negative to prevent short circuit
Charging state（closed circuit voltage）inspection
Open the cushion
Remove the cover of battery container. 。
First remove the negative wire and then
remove the positive wire.
Take out the battery.
Measure the voltage between battery terminals。
Full charge：13.1V
Under charge：12.3V（Keep the battery idle for 1 hour）
* Note
Charge state examination must use a voltmeter operation.
电瓶架：battery bracket 伏特表：voltameter
Charge
Connection method：
Connect the battery charger positive pole and battery
positive pole together.
Connect the battery charger negative pole and battery
