- 48 -
Remove the oil level gauge (1) after the engine stopped.
The oil level between the upper limit and lower limit of oil level gauge is all right.
Add gear oil when the oil level is below the lower limit.
Install the oil level gauge.
Gear oil replacement
Warm-up the engine
A lacquer tray shall be placed under the engine to hold the
oil.
Remove the release bolt (2) and oil level gauge (1).
Recoil starting the engine for several times, and discharge the
engine oil completely.
Check the oil level gauge when the engine oil is discharged.
Ensure the oil level gauge and O-shape ring is all right, and
then carry out the installation.
Tighten the release bolt.
Fill the crank case with recommended engine oil.
Install the oil level gauge, start the engine, and keep it idle
running for 2-3 minutes.
Stop the engine, and check out whether the oil level is at the upper limit of oil level gauge after several minutes.
The engine shall be kept upright during inspection.
Guarantee that there's no leakage exist.
*Note:
Confirm whether the bolts wear or not.
Drive belt
Remove the cover of left crank case.
Check whether the drive belt is work or damaged.
Periodically maintenance shall be guaranteed, and replace the
drive belt with a new one if necessary.
驱动皮带:driver belt
Free path of front/rear brake
Free path of front brake
