- 97 -
1 steering handle welding assembly 2 left handle gloves 3 left nut 4 left rearview mirror assembly 5 right
rearview mirror assembly 6 right nut 7 right handle assembly 8 throttle line assembly 9 bolt
M10X1.25X50 10 handle stand compression block 11 nut M10X1.25 12 left rocker arm support 13 rear
brake cable assembly 14 pin 12 X22 15 regulating nut CM6-12X15 16 rear brake spring 17 cable clamp
assembly 18 front brake switch assembly
7.Front wheel/front suspension
Preparation documents-------------------------7.1
Failure diagnosis-------------------------7.2
Front wheel-------------------------7.3
Steering handle---------------------------7.4
Front fork-------------------------7.5
7.1 Preparation documents
Notes
Before removing the front wheel, you should use jack to let it float above the ground and it cannot be rotated.
Pay attention that no oil stains sticking to the brake shoe, brake shoe assembly and brake disc while operating.
Entire motorcycle standards
Measuring position Item
Standard
value(mm)
Available limits(mm)
Front wheel axle Bow 0.2
vertical 2.0
Front wheel
Rim
shimmy
horizontal Within 1.0 2.0
Torque force Tools
Standing bolt for steering handle welding assembly 40-60 N·m bearing replacing bar
Front wheel axle 55-62 N·m standing bolt spanner
Standing bolt of front shock absorber assembly 37-44 N·m
