Generic Onyx 50 User Manual

- 106 -
8.Rearwheel/rear suspension
Preparing documents -----------------8.1
Failure diagnosis -----------------8.2
Rear wheel -----------------8.3
Rear shock absorber-----------------8.4
8.1 Preparing documents
Notes
No oil stains sticking to the brake shoe and disc.
Preparing standards
Item Standard
value
（mm）
Available limits（mm）
Vertical 2.0 Amplitude of fluctuation of
the rear wheel
Horizontal 2.0
Locking torque force:
Rear wheel standing nut 100 - 113 N·m
Rear shock absorber bolt on the top 37 - 44 N·m
Rear shock absorber bolt at the bottom 22 - 29 N·m
8.2 Failure diagnosis
8.2.1 Swinging rear wheel
Deformed rim
Failed tyre
Untight rear wheel
Pressure shortage of tyre
8.2.2 Too soft shock absorber
