- 43 -
Adjust the free tavel of accelerator. Fisrt loosen the locked nut ①,
Fix or loosen the adjusting device ②,
Until the free travel meet the standard value,
Then fix the locking nut ①.
Air filter
Filter replacement
Remove the body shield,
Remove the set bolt (13) on the air filter,
Remove the fixing component,
Remove the air filter
Remove the the set bolt （12） on the upper cover of air filter,
Remove the filter element （4） on the filter.
Check weather the filter element is polluted or damaged.
And replace it with a new element if necessary
Remove the pipe clip.
Remove the filter.
Check weather the filter is polluted or damaged.
And replace it with a new one if necessary.
Replacement time
Replace at an early time if the motorcycle is always running
on rainy days.
*Note
•Make sure the air filter cap is well installed before installing
the filter
Spark plug
Disconnect the connecting wire of plug cap
①Lateral electrode ②Central electrode ③Insulator
*Note:
