Generic Onyx 50 User Manual

- 86 -
1 Vacuum tyre 90/80-16 2 Rear wheel component 16×1.85 3Bolt M16X1.5 4 Dust cover 5 nozzle
cap 6 nozzle 7 Brake pad component 8 Rear brake camshaft 9 Drag spring of brake pad \
10Bolt M6X30 11 Rear brake rocker component 12 Bolt M6
5. Brake
Maintenance instruction ------------------------5.1
Failure diagnosis ------------------------5.2
Front fluid brake --------------------------5.3
Rear fluid brake --------------------------5.4
5.1 Maintenance instruction
Note of work
* Note
* Check the brake before riding*
5.1.1Specification
Items Standard value(mm) Available limits (mm)
front brake disc diameter φ220mm -
front brake disc thickness
4.0
3.0
Thickness of friction piece in
front liquid brake
4.0
3.0
Inner diameter of rear drum
brake
φ140mm
-
Thickness of friction piece in
rear brake pad
4.0 3.0
5.1.2 Torque
Installing bolt of front liquid brake plate 5-9 N·m Set bolt of rear brake rocker 5-9 N·m
Set bolt of rear wheel 100-113 N·m
• Parts of the braking system should not be polluted when installing or removing.
•Use the required cleaner to prevent affecting the function of the braking system.
