Generic Onyx 50 - Inspection and Maintenance of Electrical System

- 53 -
Inspection and maintenance of electrical system
Torque force list of fixing parts in electrical system
Position and name of fixing componen
Torque of fixing（N·m）
Rectifier bolt
High tension coil fixing bolt
Flywheel Fixing bolt
Body Shield Bolt
Clutch cover bolt of starting motors
Set screw nut of clutch cover of starting motors
5.0
9.0
5.0
9.0
12
95
