Generic Onyx 50 User Manual

- 123 -
Natural consumption of oil No oil or low oil pressure
Oil leakage Oil line block
Abraded or badly installed piston ring No machine oil is used
11.3 Machine oil pump
11.3.1 Removal
Loose the bolt and remove gas director assembly.
导风罩 gas director
Loose screws on fan and remove fan.
风扇 fan
螺钉 screw
Remove magnetogenerator stator, rotor and support.
磁电机定子、转子、支架
Magnetogenerator stator, rotor and support
Remove worm wheel from crankshaft and remove machine
导风罩
风扇
螺钉
磁电机定子、
