- 65 -
Trigger voltage
Above 1.7V
Charging coil voltage 95-400V
Tools
Voltmeter
Multimeter
2.2 Failure diagnosis
Spark plug unable to jump
Error Reason (identify according to the following order)
Ignition
coil
Low voltage
The inner resistance is too small and it should be tested by required tester
Low rotation speed of the bent axle.
Tester is interfered. (It is normal that several measured voltage is above
the basic standard.)
Poor contact wire for the ignition system.
Bad ignition coil.
Bad charging coils (measure at maximum voltage).
No or interrupted high voltage electricity
Wrong connection with the tester.
Bad main switch
Bad connector of the CDI group
Poor contact of the CDI group or GND of the CDI group is short-circuit.
Bad charging coil (measure at maximum voltage)
Bad triggermeasure at maximum voltage
Bad high tension electricity connector
Bad CDI group (when there is no spark for the plug or - is abnormal).
Secondary
Side
voltage
Normal high voltage electricity/no spark
for the plug
Bad plug or secondary ignition coil leakage
Bad ignition coil
No high voltage electricity
 The inner resistance is too small and should be tested by required tester.
 Low rotation speed of the bent axle
 Tester is interfered. (It is normal that several measured voltage is above
the basic standard.)
 Bad charging coil- are normal
Charging
coil
No or interrupted high tension electricity
Bad ignition coil
Bad charging coil
