- 12 -
Identification of Motorcycle
1. The identification number of motorcycle frame is
marked at : *LBBB4900?8B?????*. The 9
th
digital,
10 digital and 11
th
digital respectively indicate
inspection code, year and supplier code. There are
17-digital in total. The frame sign is nailed at . See
Fig. 1-1.
Fig. 1-1
2. The serial number of engine is printed on the shell of
crankcase of engine and shall be in the format of
KW1E40QMB-4*□□□□□□□□*. Please see fig. 1-2.
Fig. 1-2
Significant Notes
1. Please apply valid Generic parts and accessories. Any part or accessory not in accordance with the design
specification of Generic Company may cause damage to engine.
2. Only metric tools are valid for maintenance and repair. Metric screws, bolts and nuts can not be exchanged with
imperial fasteners.
3. New gaskets, O-rings, cotter pins and locking pieces shall be applied for re-assembly.
4. Bolts with large diameter or positioned inside shall be fastened first and then diagonally screw down until
reaching required torque, otherwise there is special instruction.
5. Wash disassembled parts with cleanser. Lubricate all sliding surface before assembly.
6. Check whether all the parts and accessories are correctly mounted and operated after assembly.
7. Clean and remove oil before measurement. Add recommended lubricant to the lubricating areas during
assembly.
8. Apply lubricant to the surface of engine and driving system if they are dismantled for long-term storage, which
can prevent rust and dirt.
