Foot starting device
1 snap spring 2 starting claw 3 dile gear 4 idle shaft 5 starting shaft component 6 foot
starting shaft spring
Note: in operation, no oil
shall stick to triangular belt,
and shall be cleaned if any
to minimize possibility of
sliding between triangular
belt and wheel.
