Generic Onyx 50 User Manual

- 39 -
Specification
Engine
Idle speed
1900±100rpm/min
Clearance of spark plug 0.6-0.7mm
Spec. of spark plug BR 8 HSA(NGK)
Max. power (KW/r) 2.60kW/6500rpm
Max. torque (N﹒m/r)
4.36N.m/5250rpm
Frame
Free stroke of front brake lever 10-20mm
Free stroke of rear brake lever 10-20mm
Tyre Specification
Front wheel 80/80-16
Tyre pressure unit: Kpa
QJ50QT-22D
Rear wheel 90/80-16
Front wheel spindle 55-62 N·m
Torque
value
Fixing nut for rear
wheel
100-113 N·m
Certification for Related Parts
Type Name Certificate No.
Front outer tyre E11 75R-001062
Tyre
Rear outer tyre E11 75R-001063
Front lamp E9-00 1555
Position lamp E9 50R-001555
Tail lamp E9 50R-001556
Front steering lamp E9 50R-001557
Rear steering lamp E9 50R-001558
Lamps
Rear registration plate lamp E11 50R-000066
Rear-view mirror Rear-view mirror E3 001002
Horn Horn e9 1026
Reflector installed at two side of
rear mudguard
E11 020614
Reflector
The rear reflector is combined with
the rear registration plate lamp
E11 023584
