- 57 -
Bad voltage current adjustor
1.3 Battery
1.3.1 Battery removing
Rmove the rubber pad of pedal
Remove the clamp bolt and clamp of battery.
irst remove the negative wire and then
remove the positive wire.
Take the battery from the battery container.
Warning！
When removing the positive terminal, the
tools should not be contacted with the
bracket. It is dangerous that spark caused
by short circuit will spark the petrol and
break the battery.
Do not disconnect the battery during the
adjustment of motorcycle, otherwise inner
component of the motorcycle may be
damaged.
Install the battery in an opposite order.
* Note
First positive terminal then negative
terminal to prevent short circuit.
Check the charging situation.
Open the battery cover, and remove the clamp component of battery.
Remove the lead of battery.
Measure the voltage of the terminals
Full charge：13.1V
Insufficient charge：12.3V （not working for 1h）
