Enter parameter in pH transmitter
1. Press "E" on the transmitter.
2. Enter code 22 with the "+" and "-" buttons.
3. Press "E". Setting 1 displayed. Press "E".
4. Switch between the parameters with the "E" button and change the parameter value with the
"+" and "-" buttons.
Confirm all changes with the "E" button.
5. Adjust the following parameters in the "A" setup:
Operating mode (A1): pH
Cable (A2): Sym
Damping (A3): 1
Probe (A4): IsFET
Temperature sensor (A5): Pt1k
6. Go to setting 2 and adjust the following parameters in the "B" setting:
°C-process (B1): ACT
°C cal (B3): ACT
Act. temp (B4): Calibrate the temperature sensor as needed.
7. Go to output data and adjust the following parameters in the "Output data" setting:
Select type (O3):
Lin
Select area (O311): 4…20
0/4 mA (O312): 0
20 mA (O313): 14
Changing the display.
Press "+" to switch the display between:
• Non-compensated value (µS/cm)
• Temperature (°C)
• Temperature (°F)
• No value
Adjusting analog input
1. Press "E" on the pH transmitter.
2. Enter code 22 with the "+" and "-" buttons.
3. Press "E". "Setting 1" appears on the display.
4. Select "Output" with the "+" and "-" buttons.
5. Press "E". Release the button when "Select type" appears on the display.
6. Choose "SIM" with the "+" and "-" buttons.
7. Press "E".
8. Enter 6 mA with the "+" and "-" buttons.
See section Automatic calibration (2.1.6.2.2), Page 48
Page 133 of 166
<Doc_TEC><Doc_6001341502><Rel.A><Lang_en>
