INTRODUCTION
Area of application
Getinge's washer-disinfector in the 9100 series is used in medical services for washing, disinfecting at
intermediate level (A0 = 600 as standard) and drying. The washer-disinfector is used at hospitals to wash,
disinfect and dry items such as carts, containers and equipment (wash basins, bowls and similar items in
stainless steel).
Getinge's washer-disinfector in the 9100 series is used in life science for washing, disinfecting at
intermediate level (A0 = 600 as standard) and drying. The washer-disinfectors are used by animal testing
companies to wash, disinfect and dry items such as transport trolleys, racks, cages and rack equipment.
The containers should be loaded correctly on loading equipment recommended by Getinge Disinfection
AB. The customer is responsible for Installation Qualification, Operating Qualification and Performance
Qualification being performed according to EN ISO 15883 before product usage.
Incorrect use can result in damage to objects and personal injuries.
General Description
The Getinge 9100-series washer-disinfectors are large capacity, jet spray washers for mechanical
washing, intermediate level (A0 value = 600 as standard) thermal disinfection and drying of moisture and
temperature stable hospital carts, sterilization containers, material handling carts, stands and utensils.
The washer-disinfector comes in four different sizes: the 9120, 9125, 9128 and 9122 models.
Model
Door Width Door High Chamber Length /
Load Length
9120 960 (38”) 2000 (80”) 2000 (80”) Health Care (HC)
9125 960 (38”) 2000 (80”) 2500 (98”) Health Care (HC)
9128 960 (38”) 2000 (80”) 2850 (112”) Health Care (HC)
9122 1170 (46”) 2200 (86”) 2200 (86”) Life Science (LS)
Washer-disinfector options and selections
The 9100-series washer-disinfector may be equipped according to the following options and accessories.
Floor Mount or Pit Mount
For a floor-mounted washer-disinfector, ramps are required to access the washer-disinfector. The inner
floor of a pit-mounted washer-disinfector is at the same level as the area's floor.
Horizontal or Inclined Sliding Door
As standard, the door opens horizontally, straight to the side. An inclined sliding door is required if the
unit is mounted in a pit with a width of 1900-2400 mm. The sliding doors open toward the service area.
Right Side or Left Side Service Area
Provide access to components such as plumbing, valves, pumps, tanks, electrical cabinet, etc. The
location of service area on your washer can be located left or right hand.
One or two doors
One door for loading/unloading on the same side, or two doors - one for loading on soiled side and one
for unloading on clean side.
Page 9 of 166
