Buzzer
The buzzer in the control panel is program-controlled.
Cold Start Screen (0.1)
This screen is displayed when the OP30 panel is cold started. It will show while the panel boots up and
starts up communication with the PACS, before the Main Process Screen comes on. As this screen is
showing, all LEDs on the panel will be lit for test.
Panel screen
Process screen
When the washer-disinfector has started up, the Cold Start Screen is replaced by either screen 1.1, 1.2
or 1.3. If no active selection is made, screen 1.1 appears after start-up.
Screens (1.1), (1.2) and (1.3) display the values for the process.
These screens contain the "MENU", "SELECT PROGRAM" and "EDIT VALUES" buttons, which brings up
other screens.
Page 30 of 166
<Doc_TEC><Doc_6001341502><Rel.A><Lang_en>
