Adjustment of crush protection for doors
The switch for the door's crush protection is adjustable horizontally. Adjust the sensor's position so it is
as close to the crush protection plate as possible, without being activated.
15°
15°
001759
The sensor's joint can be adjusted to achieve the right position.
Check that the point of impact for activated/non-activated switches is distinct and that the breakpoint is
not in the switch's outer area.
Page 143 of 166
