Detergent system
508100
321 4
10
8
12
7
6
5
9
11
Pos Item Name
1 B23 Flow sensor, detergent 1
2 B24 Flow sensor, detergent 2
3 B25 Flow sensor, detergent 3
4 B26 Flow sensor, detergent 4
5 M03 Dose pump, detergent 1
6 M04 Dose pump, detergent 2
7 M05 Dose pump, detergent 3
8 M06 Dose pump, detergent
9 B13 Level switch, detergent 1
10 B14 Level switch, detergent 2
11 B15 Level switch, detergent 3
12 B16 Level switch, detergent 4
Page 156 of 166
