WASH 1 STANDARD
VALUE (type)
PF01 WASH1 SELECTOR: value 0.1
Wash 1 selector (Main parameter for selecting or deselecting the whole
wash 1.)
1 (P)
CT01 WASH1 FILLTYPE: value 1, 2, 3, 4, 5 (CW, HW, CW+HW, booster, HCW)
Switch for water type for Wash 1 (parameter for selecting water type to be
used in wash 1
1=cold water, 2=hot water, 3=mixture of cold and hot water, 4=filling from
booster tank, 5=high quality water).
3 (P)
LI01 WASH1 TEMP SP-value 20-90°C
Wash 1 temperature set point.
60°C (P)
TI00 WASH1 TIME: value 0-60 min
Wash 1 time at selected wash 1 temperature set point
2 min (P)
LI07 WASH1 DOS TEMP: value 0-60°C
Wash 1 detergent dosing temperature set point.
45°C (P)
CT06 WASH1 DOS PUMP: value 0, 1, 2, 3, 4
Wash 1 detergent dosing pump selector (0=no pump, 1=pump 1, 2=pump
2, 3=pump 3, 4=pump 4)
1 (P)
PF20 WASH1 TANK: value 0.1
Switch for saving tank for wash 1. (0=no saving tank used when filling and
draining wash 1, 1=saving tank 1 always used for filling and emptying wash
1) (saving tank 1 always dedicated to wash 1, saving tank 2 and always
final wash)
1 (P)
PF27 WASH1 DOS TYPE: value 0-1 (normal amount based, Conductivity
monitor)
Wash 1 detergent dosing type selector. (0=detergent dose based on
normal amount,
1=Conductivity controlled, detergent dosing at preset conductivity for
water and detergent mixture)
0 (P)
LI32 WASH1 DOSCOND SP: value 0-5000 µS/cm
Set conductivity for detergent dosing for wash 1. (It is very important if this
function is used that the conductivity sensor is properly checked and
calibrated, and recalibrated every second month, and that if the detergent
types are changed, a new start up has to be performed.)
Affects the process if PF27 is 1 only.
1000 µS/cm (P)
PF25 WASH1 SOAK: value 0.1
Wash 1 soak selector. (0=no soak function, 1=soak function in 1-10 min
after 1-10 min of washing). The soak function is used when you want to
pause the main pump somewhere during the ongoing wash, e.g. the main
pump, and everything else, stops after 1 min of washing and is kept
stopped for 1 min and the washing will go on for the rest of the selected
total washing time.
0 (P)
Page 70 of 166
<Doc_TEC><Doc_6001341502><Rel.A><Lang_en>
