Pos Item Name
1 M15.2 Motor 1, nozzle turn
2 E04 Machine light 2
3 M11 Door, motor soiled side
4 V19.1 Cylinder 2, cart connection incline
5 V21.1 Cylinder 1, locked door soiled side
6 S01.1 Limit switch, door soiled side locked 1
7 S02.1 Limit switch, door soiled side unlocked 1
8 V21.2 Cylinder 2, locked door soiled side
9 S01.2 Limit switch, door soiled side locked 2
10 S02.2 Limit switch, door soiled side unlocked 2
11 S07 Limit switch, door open clean side
12 Drain tank
13 V20 Cylinder, threshold soiled side
14 S11 Limit switch, door soiled side threshold out
15 V12 Valve, waste water from tank 1
16 A114 Printer (Cobex)
17 A113 Operating panel OP30
18 S101, S102 Machine stop, door soiled side auto
19 B17 Level switch, drain tank
20 V08 Valve, drain tank
21 S04 Limit Switch, Door Close
22 V15 Valve, drain cooling
23 B07 Temperature sensor, drain cooling
Page 155 of 166
<Doc_TEC><Doc_6001341502><Rel.A><Lang_en>
