Firmware Version 1.0.3.46

GXV3275 User Guide

Page 25 of 187

Item

Name

Description

Camera Adjusting

Wheel

Scroll up/down to adjust the camera angle.

Phone Stand (built-in)

Adjust the phone stand angle to place the phone on the

desk.

Power Jack

12V DC Power connector port.

PC Port

10/100/1000Mbps RJ-45 port connecting to PC.

LAN Port

10/100/1000Mbps RJ-45 port connecting to Ethernet. PoE is

supported.

Headset Port

RJ9 headset connector port (supporting EHS with

Plantronics headset).

Handset Port

RJ9 handset connector port.

Side Connectors Cover

Open the cover for USB port, SD card slot, 3.5mm headset

port and mini HDMI port.

SIDE VIEW

Figure 3: GXV3275 Side View

Table 5: GXV3275 Side View
