71
3rd Wave User Manual
Arpeggiator
MODE: (up, down, up+down, random, assign) Selects among the various
arpeggiator modes shown in the display. You can scroll through these
and choose their settings with the the soft knobs and soft buttons. See the
table below for details on each mode.
Mode Behavior
Up Plays from lowest to highest note
Down Plays from highest to lowest note
Up + Down Plays from lowest to highest and back to lowest
Random Plays notes in random order
Assign Plays notes in the order the keys were pressed
RANGE: (1 octave, 2 octave, 3 octave) Set to 1 octave, only the held notes
are arpeggiated. Set to 2 octaves, the held notes and the notes one octave
above them arpeggiate. Set to 3 octaves, the held notes and the notes one
and two octaves above them arpeggiate.
NOTE VALUE: (see table below) Selects a basic note value relative to the
Tempo/BPM. See the table.
Value Delay Time
Whole (1) 4 beats
Half dot (2D) 3 beats
Half (2) 2 beats
Quarter dot (4D) 1 1/2 beats
Quarter (4) 1 beat
Quarter triplet (4T) 1 1/3 beats
8th dot (8D) 3/4 of 1 beat
8th (8) 1/2 of 1 beat
8th triplet (8T) 1/3 of 1 beat
16th dot (16D) 3/8 of 1 beat
16th (16) 1/4 of 1 beat
HOLD LATCH MODE: (normal. chord) Controls the behavior of the arpeggiator
when the
hold button is on. In normal mode, playing new notes will add them to
the arpeggio. In chord mode, playing new notes will replace the previous notes.
To access this feature, press soft button 4 in the Apeggiator screen.
