Port Status: S -- Selected, U -- Unselected, I -- Individual
Port: A -- Auto port, M -- Management port, R -- Reference port
Flags: A -- LACP_Activity, B -- LACP_Timeout, C -- Aggregation,
D -- Synchronization, E -- Collecting, F -- Distributing,
G -- Defaulted, H -- Expired
Aggregate Interface: Bridge-Aggregation1
Aggregation Mode: Static
Loadsharing Type: Shar
Management VLANs: None
Port Status Priority Oper-Key
WGE1/0/1(R) S 32768 1
WGE1/0/2 S 32768 1
Aggregate Interface: Bridge-Aggregation2
Aggregation Mode: Static
Loadsharing Type: Shar
Management VLANs: None
Port Status Priority Oper-Key
WGE1/0/3(R) S 32768 2
WGE1/0/4 S 32768 2
The output shows that:
• Link aggregation groups 1 and 2 are both load-shared Layer 2 static aggregation groups.
• Each aggregation group contains two Selected ports.
# Display all the group-specific load sharing modes on Device A.
[DeviceA] display link-aggregation load-sharing mode interface
Bridge-Aggregation1 Load-Sharing Mode:
source-mac address
Bridge-Aggregation2 Load-Sharing Mode:
destination-mac address
The output shows that:
• Link aggregation group 1 distributes packets based on source MAC addresses.
• Link aggregation group 2 distributes packets based on destination MAC addresses.
Example: Configuring a Layer 2 edge aggregate interface
Network configuration
As shown in Figure 11, a Layer 2 dynamic aggregation group is configured on the device. The server
is not configured with dynamic link aggregation.
Configure an edge aggregate interface so that both Twenty-FiveGigE 1/0/1 and Twenty-FiveGigE
1/0/2 can forward traffic to improve link reliability.
