2. Configure Device B in the same way Device A is configured. (Details not shown.)
3. Configure hosts:
a. Configure Host A and Host C to be on the same IP subnet. For example, 192.168.100.0/24.
b. Configure Host B and Host D to be on the same IP subnet. For example, 192.168.200.0/24.
Verifying the configuration
# Verify that Host A and Host C can ping each other, but they both fail to ping Host B and Host D.
(Details not shown.)
# Verify that Host B and Host D can ping each other, but they both fail to ping Host A and Host C.
(Details not shown.)
# Verify that VLANs 100 and 200 are correctly configured on Device A.
[DeviceA-Twenty-FiveGigE1/0/3] display vlan 100
VLAN ID: 100
VLAN type: Static
Route interface: Not configured
Description: VLAN 0100
Name: VLAN 0100
Tagged ports:
Twenty-FiveGigE1/0/3
Untagged ports:
Twenty-FiveGigE1/0/1
[DeviceA-Twenty-FiveGigE1/0/3] display vlan 200
VLAN ID: 200
VLAN type: Static
Route interface: Not configured
Description: VLAN 0200
Name: VLAN 0200
Tagged ports:
Twenty-FiveGigE1/0/3
Untagged ports:
Twenty-FiveGigE1/0/2
Example: Configuring MAC-based VLANs
Network configuration
As shown in Figure 4:
• Twenty-FiveGigE 1/0/1 of Device A and Device C are each connected to a meeting room.
Laptop 1 and Laptop 2 are used for meetings and might be used in either of the two meeting
rooms.
• One department uses VLAN 100 and owns Laptop 1. The other department uses VLAN 200
and owns Laptop 2.
Configure MAC-based VLANs, so that Laptop 1 and Laptop 2 can access Server 1 and Server 2,
respectively, no matter which meeting room they are used in.
