Introduction
introdUction
The following is a visual introduction to a HAAS mill. Some of the features
shown will be highlighted in their appropriate sections.
.
Tool Changer
(Umbrella Type)
Spindle
Optional
P-Cool
Assembly
Coolant Nozzles
SMTC
Double Arm
Tool Release Button
V
F
Work Beacon
Clip Board
Operator Manual
& Assembly Data
(Stored inside)
Vise Handle
Holder
Hold to Run
G&MCode
Reference List
Remote Jog
Control
Tool Tray
1
2
3
4
View Rotated 90° CCW
View Rotated 90° CCW
Control
Pendant
Servo
Autodoor
Opener
(Optional)
Chip
Conveyor
(Optional)
Side Mount Tool
Changer (SMTC)
Spindle Head
Assembly
Tool
Holding
Vise
Tool Tray
2X High Intensity Lights
2 Switches:1on Lights
1on Header Bar
(Optional)
Front Work Table
Chip
Container
Air Gun
2X Work Light
Electrical
Control Box
Secure Work Platform to Machine
Using Chains to Enclosure and/or Bolts
to the Floor
See
Below
Pendant Side Panel Symbols
2
USB
Write to Memory
(Lock/Unlock)
Setup Mode
(Lock/Unlock)
Second
Home
Autodoor
Override
Light Toggle
(x2)
