131 - Auto Door
This setting supports the Auto Door option. It should be set to On for machines
with an autodoor. Also see M80/81 (Autodoor Open/Close M-codes).
The door will close when Cycle Start is pressed and will open when the pro-
gram reaches an M00, M01 (with Optional Stop turned on) or M30 and the
spindle has stopped turning.
133 - REPT Rigid Tap
This setting ensures that the spindle is oriented during tapping so that the
threads will line up when a second tapping pass, in the same hole, is pro-
grammed.
142 - Offset Chng Tolerance
This setting generates a warning message if an offset is changed by more than
the amount entered for this setting. The following prompt will be displayed: “XX
changes the offset by more than Setting 142! Accept (Y/N)?” if an attempt is
made to change an offset by more than the entered amount (either positive or
negative), If “Y” is entered, the control updates the offset as usual; otherwise,
the change is rejected.
If “Y” is entered, the control updates the offset as usual, otherwise, the change
is rejected.
143 Machine Data Collect
This setting enables the user to extract data from the control using one or more
Q commands sent through the RS-232 port, and to set Macro variables by us-
ing an E command. This feature is software-based and requires an additional
computer to request, interpret and store data from the control. A hardware
option also allows the reading of machine status. See the CNC Data Transfer
section for detailed information.
144 - Feed Overide->Spindles
This setting is intended to keep the chip load constant when an override is ap-
plied. When this setting is On, any feedrate override will also be applied to the
spindle speed, and the spindle overrides will be disabled.
146 - APC Pallet 3 Load X
147 - APC Pallet 3 Load Y
148 - APC Pallet 3 Unload X
149 - APC Pallet 3 Unload Y
150 - APC Pallet 4 Load X
151 - APC Pallet 4 Load Y
152 - APC Pallet 4 Unload X
153 - APC Pallet 4 Unload Y
154 - APC Pallet 3 & 4 Safe X
See Settings 121-129
