fU n c t i o n Ke y S
F1- F4 Keys - These buttons have different functions depending on mode of
operation. See the specic mode section for further descriptions and examples.
Tool Offset Meas (Tool Offset Measure) - Used to record tool length offsets
during part setup.
Next Tool - Used to select the next tool from the tool changer. Used after
pressing Tool Offset Measure in Setup.
Tool Release - Releases the tool from the spindle when in MDI mode, zero
return mode, or handle jog mode.
Part Zero Set - Used to record work coordinate offsets during part setup (see
Setting Offsets in the Operation section).
Jo G Ke y S
Chip FWD (Chip Auger Forward) - Starts optional chip auger in the “Forward”
direction, moving chips out of the machine.
Chip Stop (Chip Auger Stop) - Stops auger movement.
Chip REV (Chip Auger Reverse) - Starts the optional chip auger in the “Re-
verse” direction, which is useful in clearing jams and debris from the auger.
X/-X, Y/-Y, Z/-Z, A/-A and B/-B (axis keys)- Allows manually jogging of axis by
holding down the individual button or by pressing the desired axis button and
using the jog handle.
Jog Lock - Works with the axes buttons. Press jog lock and then an axis but-
ton and the axis will move to maximum travel or until jog lock is pressed again.
CLNT Up (Coolant Up) - Moves the optional Programmable Coolant (P-Cool)
nozzle up.
CLNT Down (Coolant Down) - Moves the optional P-Cool nozzle down.
AUX CLNT (Auxiliary Coolant) - Pressing this key while in MDI mode only will
turn on the optional Through the Spindle Coolant (TSC) system; pressing it a
second time will turn off TSC.
ov e r r i d e Ke y S
These keys give the user the ability to override the speed of non-cutting (rapid)
axes motion, programmed feeds and spindle speeds.
-10 - Decreases current feedrate by 10%.
100% - Sets overridden feedrate to programmed feedrate.
+10 - Increases current feedrate by 10%.
