Technical information
4 Technical information
4.1 Dimensions and weight
A
E
B
C
C1
D min.
D max.
Fig. 1: Dimensions A2-26
Basic machine
Data Value Unit
Space requirement A x B 690 x 440 mm
Total height C (Planing) 910 mm
Total height C1 (Thickness planing) 1300 mm
Total width D min. / max. 970 mm
Total length E 1130 mm
Net weight *) 150 kg
*) incl. planer fence
P
ackaging dimensions (incl. pallet)
Data Value Unit
Total height C 800 mm
Total width D 560 mm
Total length E 1100 mm
Net weight 175 kg
