Transporting, packing, storing
6.4 Transport locking device
Fig. 13: Remove the transport bracket
1 Transport brackets
2 Chipboard screws TX 30
The machine is delivered partially assembled on a pallet.
T
he machine is attached to the pallet with several transport brackets. Only remove
the transport bracket when the machine is to be lifted from the pallet.
6.5 Information relating to transportation and unloading
NOTICE
Material damage
Damag
e and possible complete write-off of the machine.
− Only lift the machine using the positions marked.
− Never lift the machine using the work tables.
− Only transport the machine using a forklift or a pallet truck.
Fig. 14: Transportation and unloading
1 Do not lift!
