4.2 Operation and storage conditions
Data Value Unit
Operating/room temperature +5 - +40 °C
Storage temperature -10 - +50 °C
Humidity (non-wetting) 90 %
4.3 Electrical connection
Data Value Unit
Mains voltage according to specifica-
t
ion plate
±10 %
Frequency according to data plate 50 / 60 Hz
Power supply cable 1 x 230 V (H07
R
N-F)
3 x 1.5 mm²
Fuse protection see the wiring
diagram
Triggering characteristic C
4.4 Drive motor
T
he actual values can be found on the machine nameplate on the components.
Alternating-current motor
Data Value Unit
Motor voltage (standard) 1 x 230 V V
Motor frequency 50 / 60 Hz
Protection class IP 54
Motor power S6 1.9 kW
4.5 Planing unit
T
he machine is equipped with a machine specific, marked cutterblock,
● which has a permissible maximum rotation speed that is higher than the
ma
ximum possible rotation speed of the machine.
● which complies with the standard DIN EN 847-1:2013.
● which is marked with "MAN".
