Machine overview
5.2 Pictograms, signs and labels
All the pic
tograms, signs and labels affixed to the machine must be kept visible,
readable and must not be removed.
1
2
3
4
5
6
7
Fig. 3: Pictograms overview
1 Machine data plate (rear side)
2 Danger, electric current
3 Depth of cut scale (planer)
4 Scale workpiece thickness (thicknesser)
5 Scale angle adjustment (planer fence)
6 Changeover position information (thicknessing table)
7 Clamping information (thicknessing table)
23
4
5
6 7
Fig. 4: Overview individual pictograms
