● The machine is equipped with safety limit switches. The planer shaft can
only run when the planer tables are closed or the extractor hood is tilted up.
● The machine is equipped with a motor protection device that switches the
mac
hine off in the event of an overload.
5.5.2 Cutterblock cover
Fig. 9: Cutterblock cover
1 front cutterblock cover (bridge guard)
2 rear cutterblock cover
Bridge guard (front cutterblock cover)
T
he bridge guard covers the cutterblock when surface planing. Instructions to
adjust the bridge guard are given in the respective working techniques descrip-
tions.
Rear cutterblock cover
When surface planing, the rear cutterblock cover screens the part of the cutter-
block that remains exposed behind the fence.
This cover is mounted to the planer fence and does not need to be adjusted
separately.
