Only the following working techniques are permitted with the planer unit:
● Planing the broadside of a workpiece.
● Planing the narrow side of a workpiece.
● Bevelling the narrow side of a workpiece.
● Chamfering the edges of a workpiece.
● Always work from right to left in front of the machine.
9.2.3 Prohibited work techniques planing
T
he following working techniques are absolutely forbidden with the planer unit:
● Synchronous planing (the rotational direction of the cutterblock is the same
a
s that of the feed direction).
● Insert planing (the full length of the workpiece is not machined).
● Planing workpieces that are very warped.
● Rabbet planing using the end of the cutterblock.
9.2.4 Workpiece dimensions (planing)
WARNING
Risk of injury from workpiece parts
Splinter
ing workpieces when working at a larger depth of cut
(4mm)
− When processing workpieces that are thinner than 10 mm,
onl
y set a small depth of cut (max. 10% of the workpiece
thickness).
− The finished planed workpiece must not be thinner than 6 mm.
When using appropriate auxiliary equipment and observing the safety distances
t
o the surroundings, there are no limits to the workpiece length.
Length less than 250 mm only work with special equipment (e.g. push stick).
Length longer than 1500 mm only work with table extensions or with a second person.
Width max. 260 mm
Thickness min. 10 mm (without suitable auxiliary material)
9.2.5 Work process with permitted working methods
P
ersonnel:
● Trained machine operator
Pr
otective equipment:
● Push stick, push grip
R
equirements
● Switch the machine off before you start.
● Extraction system is connected.
● Close the planer tables or tilt away the extraction hood.
1.
Ensure sufficient support surfaces (accessories).
