Hammer A2-26 - Transporting with a Forklift; Transport with a Rolling Carriage

35
A2-26
Transporting, packing, storing
6.6.2 Transporting with a forklift
WARNING
Tipping over of the machine
S
erious injury due to the high machine weight
− Consider the centre of gravity of the machine.
− Depending on the equipment, two or three additional helpers
ar
e required when unloading.
− Lifting material (straps, chains and fork lifts) must be positioned
a
s far apart away from the centre of gravity as possible.
1
2
Fig. 16: Transport with a forklift truck
1 Recesses in the pallet
2 Do not remove the transport bracket
Move the forks of the forklift truck so they fit into the machine frame or pallet
hole
s.
6.6.3 Transport with a rolling carriage
The rolling carriage and the lifting bar (option) facilitate the task of transporting
the machine.
