MIDI STRUCTURE
is keyboard has “Keyboard Channels” to transmit playing information of the key-
boards and “External Zone Channels” to control external MIDI equipment on the
keyboards.
KEYBOARD CHANNELS
e Keyboard channels transmit the playing information of the Upper, Lower and
Pedal parts. ese are used to exchange playing information with an external sequenc-
er.
rough the Upper channel, besides the keyboard information, that of each control-
ler is transmitted.
EXTERNAL ZONE CHANNELS
e External Zone channels are for using this keyboard as a simple master keyboard
to control the external MIDI equipment. ese are Patch parameters, and it is pos-
sible to make diff erent settings to each Patch.
ere are 3 external zones in total. Each can be allocated to the desired keyboards
(for example, 3 zones for the Upper keyboard and 1 each for the U/L/P keyboards).
EXPANDED KEYBOARDS
When the MIDI keyboard is expanded for Lower and Pedal parts, they behave as
if the built-in keyboard on the keyboard, and, not only sounds the built-in sound
generator, but also are transmitted through the MIDI OUT jack to the keyboard
channels as well as transmitted to the external zones.
Map of the
MIDI structure
on
Sk1
Extra Voice
Section
Organ
Section
Internal (Upper) Keyboard
Octave Shift (button)
Octave Shift (part)
Octave Shift (zone)
On/Off & MIDI Channel
Allocate
Key Range
ExZone 3
ExZone 2
ExZone 1
Upper
Manual Bass
Lower
Split Point
Upper Kbd.
Lower Kbd.
Pedal Kbd.
to MIDI OUT
To Next Page
