Owner’s Manual
90
PIPE
In this mode, you edit the characteristics of each pipe.
To locate this mode:
See “Function mode” (P. 68) for operation details.
❶ PIPE NUMBER
Select the PIPE which you desire to edit using [S],[T] buttons, or move the Draw-
bar which corresponding the pipe stop.
ere are 20 pipes which according to Drawbars from “Bourdon 16´” to “Principal
Chorus 4´ + Mixture IV” (P. 48).
❷ VOLUME (Pi)
Adjusts the volume of the pipe. e setting range is 0 to 127.
❸ DETUNE (Pi)
Detunes the pitch of pipe from accurate pitch by cent (⁄ of semitones).
e setting range is -50 - 0 - +50.
❹ CHIFF (Pi)
Sets the “Chiff ” noise of beginning of notes.
OFF: No sounds the chi noise.
SOFT: Sounds the chi noise slightly.
MID: Sounds the chi noise medium.
LOUD: Sounds the chi noise maximum.
NOTE: Some pipes does not a ect the chi parameter i.e. “Hautbois 8´”.
❺ CUT OFF FREQUENCY (Pi)
Adjusts the tone quality of the pipe.
e setting range is -64 to 0. At 0, all of pipe sounds are heard. e sound becomes
mellower by the decreasing the value.
❻ PAN - DIRECTION (Pi)
Adjusts the basic direction of the pipe.
e setting range is L64 - C - R63 (Left - Center - Right).
DETUNE
The beating is heard by sounding detuned pitch
on sounding accurate pitch.
Each pipe can be detuned for comfortable beating.
But it may become out of tune if too much detune
is applied.
Generally, they are e ective when set at “-” side for
lower octave pipes, set at “+” side for upper octave
pipes.
MENU/
EXIT
ENTER
❶ ❷❸ ❹ ❺ ❻ ❼
