Hammond SK2 User Manual

145
Appendix
Global Parameters
Category Parameter NRPN SysEx Address SysEx
Length
Data Default Description
LSB
(62)
MSB
(63)
MSB to LSB
Tune
Transpose
01 00 00 01 00 01
3A - 40 - 46
(-6 - 0 - 6)
40 0
Master Tune
01 02 00 01 02 02
032E - 0338 - 0342
(430 - 440 - 450)
0338 440
Expression
Source
02 00 00 02 00 01
00 - 01
00: Pedal (normal)
01: Pedal (reverse)
02: MIDI
03: Both (normal)
04: Both (pedal)
00 Pedal (normal)
Min. Level
02 08 00 02 08 01
00 - 09
(Off , -40dB - 0dB)
06 -35dB
Min. Limit LF
02 09 00 02 09 01
00 - 08
(Off , -40dB - -5dB)
05 -20dB
Min. Limit HF
02 0A 00 02 0A 01
03 -30dB
Foot Switch
FS Device
03 00 00 03 00 01
00 - 01
(Foot Sw., Leslie Sw.)
00 Foot Sw.
FS Tip Mode
03 01 00 03 01 01
00 - 25
00: Off
01: Leslie Fast (alternate)
02: Leslie Fast (momentarily)
03: Leslie Fast (tri-state)
04: Glide
05: Patch Fwd.
06: Patch Back
07: Favorite Fwd.
08: Favorite Back
09: Spring Shock
0A: Delay Time
0B: Music Start
0C: Manual Bass
0D - 25: Bass 1C - 3C
26: Prochord Close
27: Prochord Open
01 Leslie Fast (alternate)
FS Ring Mode
03 02 00 03 02 01
same as FS Tip mode 01 Leslie Fast (alternate)
Damper Org. Upper
03 03 00 03 03 01
00, 01 (Off /On) 01 On
Damper Org. Lower
03 04 00 03 04 01
00, 01 (Off /On) 01 On
Damper Org. Pedal
03 05 00 03 05 01
00, 01 (Off /On) 01 On
Damper Extra Voice
03 06 00 03 06 01
00, 01 (Off /On) 01 On
Panel Switch
Octave Down Mode
03 07 00 03 07 01
00 - 07
00: Origin
01: Leslie Stop
02: Leslie Fast
03: Vibrato Upper
04: Vibrato Lower
05: Glide
06: Spring Shock
07: Delay Time
00 Origin
Octave Up Mode
03 08 00 03 08 01
same as above 00 Origin
Octave Lower Mode
03 09 00 03 09 01
same as above 00 Origin
Patch Load
Drawbar Regist. Upper
60 00 00 60 00 01
00, 01 (Off /On) 01 On
Drawbar Regest. L/P
60 01 00 60 01 01
00, 01 (Off /On) 01 On
Drawbar Parameters
(DRAWB)
60 02 00 60 02 01
00, 01 (Off /On) 01 On
Extra Voice (EXV)
60 03 00 60 03 01
00, 01 (Off /On) 01 On
Internal Zone (INT)
60 04 00 60 04 01
00, 01 (Off /On) 01 On
External Zone (EXT)
60 05 00 60 05 01
00, 01 (Off /On) 01 On
Organ Eff ect (DRAWB)
60 06 00 60 06 01
00, 01 (Off /On) 01 On
Extra Voice Eff ect (EXV)
60 07 00 60 07 01
00, 01 (Off /On) 01 On
Reverb (REV)
60 08 00 60 08 01
00, 01 (Off /On) 01 On
Animation (ANI)
60 09 00 60 09 01
00, 01 (Off /On) 01 On
Favorites
Overwrite Patch
04 00 00 04 00 01
00, 01 (Off /On) 00 Off
Display
Short Cut
-- -- -- -- -- --
0, 1, 2s, No
Time Out
-- -- -- -- -- --
4, 8, 16s, No
Pop Up
-- -- -- -- -- --
No, 0.5, 1, 2s
Master EQ
Bass Freq.
02 0F 00 02 0F 01
00 - 0A (20 - 200Hz) 07 100Hz
Treble Freq.
02 10 00 02 10 01
00 - 03 (4.0k - 8.0kHz) 03 8.0kHz
Example Set Transpose at 0 via NRPN ................................Bx 62 01 63 00 06 40 (x = Upper channel)
Set Transpose at 0 via System Exclusive .................F0 55 dd 10 1D 13 00 01 00 40 F7 (dd = Device ID)
