88 MIDI
Hammond XK-2 Quick Features Guide
MIDI Implementation - Each Channel
ORGAN ZONES EXT. ZONES EXP CONT
UM LM PK ZONE1 ZONE2
OUT IN
OUT IN OUT IN OUT IN OUT IN OUT IN
MIDI CHANNELS 1~16, OFF 1~16, OFF 1~16, OFF 1~16
OFF
× 1~16
OFF
× INDI. 1~16,
INDI.
PROGRAM CHANGE • • × × × × • × • × × ×
PITCH BEND • • • • • • • × • × × ×
CONTROL Bank Select MSB 0
LSB 32
Modulation 1
Volume 7 (2)See note 1
Expression 11 See note 2
Tremolo 92
Hold 1 (Damper) 64
NRPN LSB 98
NRPN MSB 99
RPN LSB 100
RPN MSB 101
DATA ENTRY MSB 6
UM DRAWBAR 80
LM DRAWBAR 81
PK DRAWBAR 82
×
×
•
•
•
•
•
•
•
•
•
•
•
×
×
×
×
•
•
•
•
•
•
•
•
•
•
•
×
×
×
×
×
•
•
×
•
×
×
×
×
×
×
•
×
×
×
×
•
•
×
•
×
×
×
×
×
×
•
×
×
×
×
•
•
×
•
×
×
×
×
×
×
×
•
×
×
×
•
•
×
•
×
×
×
×
×
×
×
•
•
•
•
See note
3
•
×
•
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
•
•
•
See note
3
•
×
•
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
See note
3
•
×
×
×
×
×
×
×
×
×
×
×
×
×
×
•
×
×
×
×
×
×
×
×
×
×
AFTER CH’s
TOUCH KEY’s
×
×
•
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
Note 1: Volume data is normally received as Controllers #2 and #7.
The last data received takes priority regardless of the Controller number.
Volume data is received as Controller #2 only when “Rx. BREATH CONTROL” is “ON.”
Note 2: Expression data is normally transmitted as Controller #11, but can be changed to any other
controller number from 0 through 127.
When “MIDI EXP. CTR.” is set for “INDIV”, Expression data can be received on MIDI Channels 1
through 16.
If different MIDI channels contain different Expression data, each Manual will respond with
whatever Expression data is contained in each MIDI channel.
Note 3: If the Expression data controller number is changed to 7, Volume data will be transmitted along
with Expression data.
