92 Special Advanced Features
Hammond XK-2 Quick Features Guide
Select
EDIT PARAMETER
}34 SPLIT1
SPLIT POINT 2B
}41 ORG.ZONE-1
KEYMAP LOW 1C
Organ Zone Key Map
This Advanced Feature allows you to set the Low and High note ranges for the internal Organ Zones.
TRY THIS:
1. Touch the EDIT Select Touch Button. The red LED will light, and the Information Center Display
should look like this:
2. Touch the INT.CONT./EXT.ZONE Select Touch Button once. The Information Center Display should
look like this:
3. Touch the PAGE ”<” Select Touch Button three times. The Information Center Display should look like
this:
4. Now select the option you wish by doing the following:
Use the PAGE "<" and "=" Select Touch Buttons to select either ORG. ZONE-1 or ORG. ZONE-2. As you scroll
forward through the Manual selections, you will see the upper left-hand corner of the display change from “P41" to
“P42.”
Use the PAGE “<” and “=” Select Touch Buttons to select either “LOW” (the lower limit of the zone) or “HI” (the
upper limit of the zone).
Use the VALUE ">" Select Touch Button to scroll up through the choices.
Use the VALUE "?" Select Touch Button to scroll down through the choices.
This data CAN be stored to a Preset. To see a total listing of all Preset Parameters, see the Preset Parameter List.
NOTE: You can exit by touching the EDIT Select Touch Button.
