Hammond XK-2 Quick Features Guide
Drawbar MIDI Data
Control Change Bx 50h yy :Upper
Bx 51h yy :Lower x: MIDI channel for each manual
Bx 52h yy :Pedal yy: data
Upper / Lower Data:yy Pedal Data:yy
DRAWBAR 16' 5 1/3' 8' 4' 2 2/3' 2' 1 3/5' 1 1/3' 1' 16' 8'
Level 0 00h( 0) 09h( 9) 12h(18) 1Bh(27) 24h(36) 2Dh(45) 36h(54) 3Fh(63) 48h(72) 00h( 0) 09h( 9)
Level 1 01h( 1) 0Ah(10) 13h(19) 1Ch(28) 25h(37) 2Eh(46) 37h(55) 40h(64) 49h(73) 01h( 1) 0Ah(10)
Level 2 02h( 2) 0Bh(11) 14h(20) 1Dh(29) 26h(38) 2Fh(47) 38h(56) 41h(65) 4Ah(74) 02h( 3) 0Bh(11)
Level 3 03h( 3) 0Ch(12) 15h(21) 1Eh(30) 27h(39) 30h(48) 39h(57) 42h(66) 4Bh(75) 03h( 4) 0Ch(12)
Level 4 04h( 4) 0Dh(13) 16h(22) 1Fh(31) 28h(40) 31h(49) 3Ah(58) 43h(67) 4Ch(76) 04h( 5) 0Dh(13)
Level 5 05h( 5) 0Eh(14) 17h(23) 20h(32) 29h(41) 32h(50) 3Bh(59) 44h(68) 4Dh(77) 05h( 6) 0Eh(14)
Level 6 06h( 6) 0Fh(15) 18h(24) 21h(33) 2Ah(42) 33h(51) 3Ch(60) 45h(69) 4Eh(78) 06h( 7) 0Fh(15)
Level 7 07h( 7) 10h(16) 19h(25) 22h(34) 2Bh(43) 34h(52) 3Dh(61) 46h(70) 4Fh(79) 07h( 8) 10h(16)
Level 8 08h( 8) 11h(17) 1Ah(26) 23h(35) 2Ch(44) 35h(53) 3Eh(62) 47h(71) 50h(80) 08h( 9) 11h(17)
System Exclusive Messages
1. FORMAT
F0h
55h
[DID]
10h
0Bh
11h
[BODY]
F7h
System Exclusive
SUZUKI I.D. Number
Device No.
Model ID Number (High)
Model ID Number (Low)
Command (Data packet)
DATA
End of Exclusive
3. ACKNOWLEDGE
F0h
55h
[DID]
10h
0Bh
14h
[AK]
[PNH]
[PNL]
F7h
System Exclusive
SUZUKI I.D. Number
Device No.
Model ID Number
Model ID Number
Command Acknowledge
AK Type 00h:Normal
05h:Check Sum Error
06h:Protect SW On
Packet Number (High)
Packet Number (Low)
End of Exclusive
2. BODY
02h
[PNH]
[PNL]
[DATA]
[SUM]
Data Type (02:User program)
Packet Number(High) 0001~7F7F
Packet Number (Low)
256byte ASCII (128byte data)
Check Sum (7bit)
256byte ASCII XOR
4. HAND SHAKE COMMUNICATION
(One way transfer)
Master Slave
Data out Packet1 º
» Acknowledge
Data out Packet2 º
» Acknowledge
:
Data out Packet58 º
» Acknowledge
The organ will wait for the data for 20ms is no acknowledge is received and transmit the next data of the
packet number. (ONE WAY TRANSFER)
